3M Perforated Roll Splice Tape

Category: ,

$45.00$85.00

-
+

Crystal clear roll tape made for 3M splicers as well as Moviola, Rivas, Christy’s, Atomic, Magnasyc, Inviso, Hollywood Film, Ediquip, and many others.  Tape now features a new silicone base backing that easily peels away from the roll without leaving ratchet marks, creases, or bubbles. While the tape easily peels away from the roll, once applied to film the adhesive bonds like a rock.

Once applied to film, this innovative silicone backing also prevents splices from sticking to the film pack as the film runs trough projectors or scanners which greatly reduces the chance of film breaks or picture hiccups.

Tape material is comprised of strong polyester. It features a high shear strength acrylic adhesive that is solvent resistant and produces a reliable bond to a wide variety of substrates.  Ideal for film requiring ultrasonic or alcohol film cleaning and eventual long term storage.

Note that 16mm only comes double perforated since it can also be applied to single perf film.

35mm = 150 splices both sides per roll.

16mm  = 300 splices both sides per roll.

Backing:  Durable polyester tape backed with silicone coating.  Easily unrolls from itself while preventing sticking to the film pack.

Adhesive: Strong acrylic adhesive resistant to most film cleaning agents including alcohol, perchloroethyene, Novec and more.

Perforated Tape:  16mm and 35mm tape rolls come perforated on both edges for full frame coverage while leaving sprocket holes unobstructed.



Splicer Compatibility and Application:  For use with splicers similar to the one pictured to the left. Tape application steps are to align tape on film surface, clamp down and tear tape along the clamp edge. Spring loaded cutting blade and clamp can be seen in the picture for comparison purposes.

Package

50' 16mm Double Sided Perforation Roll Tape – $45.00, 50' 35mm Double Sided Perforation Roll Tape – $85.00

Specification

  • Crystal clear roll tape made for 3M, Moviola, Rivas, Christy’s, Atomic, Magnasyc, Inviso, Hollywood Film, Ediquip, and many others.
  • Tape has sprocket holes on both sides for all formats.
  • New silicone base backing to reduce bubbles, creases and ratchet marks.  Unique backing allows tape to easily peel away from the roll while still adhering well to film.
  • Each roll is 50′ in length.  16mm  = 300 splices both sides.  35mm = 300 splices both sides.
  • 16mm provides full frame coverage on each side.  35mm provides half frame (2 sprocket holes) coverage per side.

*Frame coverage is dependent on the splicer.  Listed coverage specifications are based on splicers built to standard specifications.
